Kryo 750 Controlled Rate Freezer for Large Number of Samples

Kryo 750

An integrated controlled rate freezer for cryopreservation of larger volume samples or samples in larger numbers - Kryo 750

The controlled rate freezer is designed for freezing of samples in bags, vials and straws.

It has a simple 2 button operation with standard PC software to enable password protected multiple protocols. A forced laminar flow cooling system ensures most efficient, even cooling and the machine has Top or Front opening for easy loading. Heated door seals prevent the lid freezing shut at cryogenic temperatures.

By using our PC software, DeltaT, enables password protected multiple protocols, online data-viewing, capture and storing for validation. Batch freezing is possible using our DeltaT software. Large sample numbers can be deposited in different machines with the subsequent freezing profile for all samples being displayed on the same graph.

Protocol stage “trigger on sample”, or chamber temperature, or time and the inner chamber is removable for sterilisation. The 750 has a Comms port - for PC connection and has flexible and fast cooling rates.

It is also available in Medical Device version.

Benefits

Top or Front opening for easy loading
Freeze samples in bags, vials and straws
Forced laminar flow for efficient and even cooling
Trigger on sample, time or temperature
Unique 2 button operation
Standard PC software enables password protected multiple protocols
Heated door seal prevents freezing shut at cryogenic temperatures
Inner chamber removable for sterilisation

Features

Chamber volume: 29 litres
Capacity: 20 x 250/500/750/1000 ml blood bags, horizontally/vertically in chamber, or 40 x 50 ml blood bags, horizontally/vertically in chamber
96 x 25ml PALL bags
Vial or ampoule capacity: 1452 x 2 ml
Straw capacity: 1216 x 2 ml
Lower temperature limit: -160 ºC
Cooling rates: -0.1 to -10 ºC/min
Controlled heating rates: 0.1 to 10 ºC/min
System controller: integral
PC Software: includes Planer's DeltaT
